MDW European Type Grinding Mill

Production Capacity:3-50t/h
Min. Output Size:0.033-1.9mm
Max. Input Size:0-50mm

Application

Power plant desulfurization, non-metallic mineral powder production, building materials and chemical industries.

Material

Limestone, calcite, dolomite, petroleum coke, gypsum, barite, marble, talc, etc.

sales@dingbocrusher.net

+8613816711123

Request for Quotation

Free Consulting Online

Overview

Technical Data

Model	Feed Particle Size (mm)	Finished Product Particle Size (mm)	Production Capacity (t/h)	Main Motor Power (kW)	Fan Motor Power (kW)	Powder Selector Motor Power (kW)	Electromagnetic Vibrating Feeder Model	Electromagnetic Vibrating Feeder Power (kW)
MDW110	<30	1.6-0.045, 0.038	3-9	55	55	7.5	GZ2F	0.15
MDW138	<35	1.6-0.045, 0.038	6-17	90	110	18.5	GZ3F	0.2
MDW215	<50	1.6-0.05, 0.038	15-45	280	315	55	GZ5F	0.65
MDW198	<45	1.6-0.05, 0.038	12-33	220	250	37	GZ4F	0.65

Features

Integrated Patent Technologies: Incorporating multiple patented technologies such as bevel gear integral transmission, internal thin oil lubrication system, and arc-shaped air duct, ensuring the operational efficiency and stability of the equipment.
Eco-Friendly and Energy-Saving Design: With industrial product environmental certification, it uses an air self-circulation system and an efficient dust collector to effectively reduce dust emissions, complying with national environmental standards and achieving green production.
High Production Efficiency: Compared to traditional mills, the MDW series European-style mill significantly improves grinding efficiency, with output increasing by over 20%, greatly enhancing production efficiency.
Convenient Maintenance and Management: Key components such as the fan and main shaft transmission system use thin oil lubrication, reducing maintenance frequency and extending the oil change cycle, making equipment maintenance simpler and more efficient.

Working Principle

Feeding: After being processed by the crusher, the material is evenly and quantitatively fed into the grinding chamber of the mill by a variable frequency belt feeder.
Grinding: Once inside the grinding chamber, the material is subjected to high-speed rotation, impact, and friction from the grinding roller and grinding ring, gradually being ground into fine powder.
Classification: The ground material rises with the airflow generated by the fan and enters the powder classifier for classification. The classifier screens the material based on particle size; particles that meet the required fineness pass through, while coarser particles return to the grinding chamber for further grinding.
Collection: The qualified fine powder, after classification, is collected by a cyclone powder collector, separating it from the air.
Discharge: The collected fine powder is discharged from the mill through the discharge device, completing the entire grinding process.
Throughout the process, the European-style mill utilizes efficient air selection technology and a precise classification system to ensure grinding efficiency and fineness control. Additionally, with an internal thin oil lubrication system and dust removal devices, the equipment's stable operation and environmental requirements are maintained.
