SF Flotation Cell

Capacity:0.2-20m³/min
Effective Volume:0.37~20m3
Material
mainly used in the flotation of nonferrous metals and rare metals, such as copper, gold, silver, zinc, lead, nickel, etc; and nonmetal materials, such as kaolinite, phosphorus, sulfur, etc.

SF flotation cell is a mechanical agitation type flotation equipment with self-slurry suction and self-air suction

Overview

Technical Data
Model Capacity
Effective Volume Lmpeller Diameter Lmpeller Revolution Motor Power for Stir Motor Power Singe Tank Weight
m3/min m3 mm r/min kw kw kg
SF-0.37
0.2~0.4 0.37 300 352~442 1.5 0.55 468
SF-0.7
0.3~1.0 0.7 350 336~384 3 1.1 629
SF-1.2
0.6~1.6 1.2 450 312 5.5 1.1 1373
SF-2
1.5~3 2 550 280 11 1.5 1879
SF-2.8
1.5~3.5 2.8 550 280 11 1.5 1902
SF-4
2.0~4 4 650 235 15 1.5 2582
SF-6
3-6 6 760 191 30 2.2 3540
SF-8
4.0~8 8 760 191 30 2.2 4129
SF-16
5.0~16 16 850 169~193 45 1.5 7415
SF-20
10~12 20 850 169~193 45 1.5 9828
Features
Large air suction volume, low power consumption
Long service life of wear parts
Each tank with air suction, slurry suction and flotation function does not need any accessory equipment to form flotation circle, which is convenient for process flow changing
The reasonable slurry circulation minimizes coarse sand sediments, and is conducive to flotation of coarse particle
Auto-control device of slurry volume, convenient adjustment
Impeller with backward style upper and lower leaf, the upper blade generates upper circulation; the lower blade generates lower circulation.
Mechanical stirring, self- air suction, self-slurry suction
SF flotation cell is composed flotation cell unit with JJF flotation cell as the suction tank of every operation
Working Principle
When the flotation machine works, the motor drives the impeller to revolve, so the centrifugal effect and negative pressure are produced. On one hand, ample air is absorbed and mixed with mineral slurry, on the other hand, the mixed mineral slurry is mingled with additive, meanwhile, the foams are thinning, the mineral is bounded with foams, and floats up to the surface of mineral slurry and the mineralized foam is formed. The liquid surface can be adjusted with the height of adjustment flashboard, so that the useful foams are scraped with squeegee.
