150-220tph Sand making plant

> SOLUTIONS > Complete Solutions > Sand Making Plant > 150-220tph Sand making plant

150-220tph Sand making plant

Raw materials
Limestone, Granite, Basalt, Quartz, River stone etc.

Application
In sand quarry, mine, construction site, highway, road and bridge construction, concrete mixing station, water conservancy and hydropower, chemical industry and other industries.

Equipment configuration
Hopper, ZSW1100x4200 vibrating feeder, PE750x1060 jaw crusher，HPC300 cone crusher (or impact crusher), VSI1145 sand making machine, Vibrating screen, Sand recycling machine, Belt conveyor.

Request for Quotation

Free Consulting Online

150-220tph Sand Making Plant Process

Jaw crusher, the jaw crusher crushes the stone in sections, the stone coming out of the jaw crusher is less than 70mm, and then transported to the impact crusher through the belt conveyor for secondary crushing, and the crushed material is sent by the belt conveyor Transport to the sand making machine for fine crushing (note: the raw ore below 40mm can be directly crushed by the sand making machine), and the crushed material is then screened by a circular vibrating screen for coarse sand, medium sand, fine sand, and other specifications.

Hydraulic cone crushers and impact crushers can all be used as secondary crushing equipment, and we can choose corresponding equipment models according to different outputs.
As a sand shaping equipment, VSI sand making machine can adjust the size of the discharge port according to the needs of customers to obtain better quality products, and finally, sieve different discharge particle sizes through sieves to obtain the final product.

For sand with strict powder content requirements, a sand washing machine can be installed behind the fine sand, and the sewage discharged from the sand washing machine can be recycled through a fine sand recycling machine.

RECOMMEND EQUIPMENT

PE Jaw Crusher

Capacity	5-800t/h
Max. Feeding Size	210-1020mm

PF Impact Crusher

Capacity	35-550t/h
Max. Feeding Size	300-700mm

HPD Hydraulic Cone Crusher

Capacity	50-1200t/h
Max Feeding Size	6-38mm

GP Single Cylinder Hydraulic Cone Crusher

Capacity	40-1000t/h
Feed Opening Size	80-350mm

VSI Vertical Shaft Impact Crusher

Capacity	70-640t/h
Max. Input Size	60mm

ZSW Vibrating Feeder

Capacity	96-1500t/h
Max. Input Size	450-1400mm

XSD Sand Washer

Capacity	20-120t/h
Max. Input Size	10mm

B Belt Conveyor

Capacity	150-900t/h
Max. Input Size	300mm

YA Vibrating Screen

Capacity	15-800t/h
Max. Input Size	200mm
